Lenovo L series laptops (ThinkPad) L15 (type 20U3, 20U4) Laptop (ThinkPad) (with HDD), Motherboard and SubBoard BoardView file* (*Silkscreen) and Schematic diagram

Click on picture to enlarge	Price: US $20.00 What's included: — 4 Schematic Diagrams for Motherboard, USB, MIC and Power Boards — 4 BoardView file* (*Silkscreen) for Motherboard, USB, MIC and Power Boards Major components: CPU/HUB/RAM: Intel CometLake-U / DDR4 GPU/VRAM : UMA or DIS (AMD Radeon 625 + 2GB GDDR5 (R19MM18-50)) EC/SIO : NPCE68APA0DX File types: Schematic Diagram(s) : PDF / Searchable Silkscreen for MB : PDF / Searchable BoardView file(s) : N/A Language : English

Click on picture to enlarge

Price: US $20.00

What's included:

— 4 Schematic Diagrams for Motherboard, USB, MIC and Power Boards
— 4 BoardView file* (*Silkscreen) for Motherboard, USB, MIC and Power Boards

Major components:

CPU/HUB/RAM: Intel CometLake-U / DDR4
GPU/VRAM : UMA or DIS (AMD Radeon 625 + 2GB GDDR5 (R19MM18-50))
EC/SIO : NPCE68APA0DX

File types:

Schematic Diagram(s) : PDF / Searchable
Silkscreen for MB : PDF / Searchable
BoardView file(s) : N/A
Language : English

Updated: 16-09-2022
