Lenovo 500 Series desktops and AIO (ideacentre) 510-15ICK Desktop (ideacentre), Motherboard Schematic diagram

Click on picture to enlarge	Price: US $20.00 Known motherboard p/n: I365MS VER: 1.0 What's included: - Schematic diagram - Power On/Off Sequence Timing Diagrams - Power Map(Power Distribution Diagram / Power Block Diagram) - Power & Reset Map - SMBus/I2C Block Diagram - Clock Block Diagram Major components: CPU/HUB/RAM : Intel CoffeeLake-S / CannonLake B365 / DDR4 GPU : UMA or DIS (PCIe Card) EC : NCT6686D-L File types: Schematic Diagram(s): PDF / Searchable BoardView file(s) : N/A Language : English BIOS file : N/A

Click on picture to enlarge

Price: US $20.00

Known motherboard p/n: I365MS VER: 1.0

What's included:

- Schematic diagram
- Power On/Off Sequence Timing Diagrams
- Power Map(Power Distribution Diagram / Power Block Diagram)
- Power & Reset Map
- SMBus/I2C Block Diagram
- Clock Block Diagram

Major components:

CPU/HUB/RAM : Intel CoffeeLake-S / CannonLake B365 / DDR4
GPU : UMA or DIS (PCIe Card)
EC : NCT6686D-L

File types:

Schematic Diagram(s): PDF / Searchable
BoardView file(s) : N/A
Language : English
BIOS file : N/A

Updated: 24-06-2021
