Compal OEM LA-A491P ZAL00, motherboard Schematic diagram
Click on picture to enlarge |
Motherboard p/n: ZAL00 LA-A491P Also included: — BoardView file and BoardView software — Power block diagram — SM Bus block diagram Major components CPU :Intel Haswell GFX :UMA or DIS (AMD Venus Pro) KBC(Embeded Controller) : KB9012 File tipe : PDF Language : English |
---|
