Packard Bell EasyNote MX51 series, Laptop motherboard Schematic diagram

Click on picture to enlarge	Price: US $18.75 Included: "Board view" file + software (viewer). Using this tool you will be able to find any component, pin or signal on your motherboard in few seconds! POWER FLOW Diagram Major components CPU :Intel AMD (Turion 64 / Sempron) Chipset :nVIDIA C51MV(NF-G6100-N-A2) // nVIDIA MCP51(NF-G430-N-A3) VGA :UMA KBC(Embeded Controller),SIO: IT8510E Audio Contr./AMP : ALC660 / G1420 LAN : RTL8101CL CardBus Contr. : R5C841/R5C832 TPC8107 78L05 TPS51020 SI9183 SI9183 ISL6227 MAX8632 MIC5235 MAX8760 MAX8725 TPC8107 CM8562 F02JK2E LM4040BIM File tipe : PDF Language : English

Click on picture to enlarge

Price: US $18.75

Included:

*"Board view" file + software (viewer). Using this tool you will be able
to find any component, pin or signal on your motherboard in few seconds!

* POWER FLOW Diagram

Major components

CPU :Intel AMD (Turion 64 / Sempron)
Chipset :nVIDIA C51MV(NF-G6100-N-A2) // nVIDIA MCP51(NF-G430-N-A3)
VGA :UMA
KBC(Embeded Controller),SIO: IT8510E
Audio Contr./AMP : ALC660 / G1420
LAN : RTL8101CL
CardBus Contr. : R5C841/R5C832

TPC8107
78L05
TPS51020
SI9183
SI9183
ISL6227
MAX8632
MIC5235
MAX8760
MAX8725
TPC8107
CM8562
F02JK2E
LM4040BIM

File tipe : PDF
Language : English

Updated: 05-12-2011
