Clevo X-series X7200, Laptop Motherboard Schematic diagram
Click on picture to enlarge |
Major components: CPU : Intel Bloomfield Chipset : Intel Tylersburg / ICH-10 Video: Dual MXM III VGA Card KBC(Embeded Controller),SIO :H8/2111 Known motherboard part numbers: 71-X7200-D00 and other : 6-71-X7200-xxx (x- digits or letters) File type : PDF Language : English |
---|
