LCFC OEM NM-A911 CG721 (+ NS-A911 CG721 & NS-A912 CG721), motherboard Schematic diagram

Click on picture to enlarge	Price: US $18.75 Motherboard p/n: CG721 NM-A911 ODD Board p/n: CG721 NS-A912 LED Board p/n: CG721 NS-A911 Also included: — 2 additional schematic diagrams for daughter boards: ODD and LED boards — 2 BoardView files for ODD and LED boards — System Power Block Diagram — Power Sequence Block Diagram (Step-by-Step) — GPU Power Up/Down Sequence Diagram Major components: CPU: AMD FP4 APU Carrizo-L with DDR3L GPU: UMA or DIS (AMD R16M-M1-30) EC: ITE IT8586E File type : PDF (Searchable) Language : English Revision: EVT

Click on picture to enlarge

Price: US $18.75

Motherboard p/n: CG721 NM-A911
ODD Board p/n: CG721 NS-A912
LED Board p/n: CG721 NS-A911

Also included:

— 2 additional schematic diagrams for daughter boards: ODD and LED boards
— 2 BoardView files for ODD and LED boards
— System Power Block Diagram
— Power Sequence Block Diagram (Step-by-Step)
— GPU Power Up/Down Sequence Diagram

Major components:

CPU: AMD FP4 APU Carrizo-L with DDR3L
GPU: UMA or DIS (AMD R16M-M1-30)
EC: ITE IT8586E

File type : PDF (Searchable)
Language : English
Revision: EVT

Updated: 24-05-2020
